position： home > Product > MXenes-Max 2D transition metal carbonitride

mxene modified conductive flexible printed circuit with high conductivity and good adhesion





ID：BK2020032301

CAS：

price：
$800


Item ID：BK2020032301-04

specification：

5 minutes to choose the product plan

E-mail：mxenes@163.com

Detailed

product information
Product name: mxene modified conductive flexible printed circuit with high conductivity and good adhesion

Product features: Good printability, electrical conductivity, high hardness and strong adhesion. This kind of product has good bending resistance, low modulus, good performance and excellent solvent resistance. Good adhesion to PET, PI, ITO substrate and FR substrate.

Typical applications: printing of electronic circuits such as membrane switches, keyboards, remote controls, flexible printed circuits and FPCs. Miniature super capacitor.

Instructions for use:
1. Applicable substrate: PET, PC, ITO, etc.
2. Stir: Stir thoroughly for 5 to 10 minutes before use.
3. Dilute: special diluent, the added proportion should not exceed 3% of the total weight.
4. Recommended process:
Printing thickness: wet film: 20μm; dry film: 4-7μm;
Silk screen: 250-300 mesh polyester or stainless steel screen printing;
Scraper: Polyurethane or solvent resistant material;
Equipment: Semi-automatic printing machine;
Curing conditions: Oven: 130 ℃ × 20 min IR furnace: 135 ℃ × 10 min (can be adjusted according to customer requirements)
Cleaning agent: acetone or diethylene glycol ether acetate.

Due to the significant environmental impact of the process, screen printing is recommended to be divided into batches and used up within 8 hours. Installing a protective cover can reduce the volatilization of product components and cut off dust particles in the air to ensure quality.

Warm tip: the products supplied by Beijing Beike Xincai Technology Co., Ltd. are only used for scientific research, not for human body

Item ID	CAS	ID	Pack	Parameter	Stock	Make up	Price
BK2020032301-01		BK2020032301	50ml	Ti3C2	100		$1250
BK2020032301-02		BK2020032301	50ml	Ti2C	100		$600
BK2020032301-01		BK2020032301	50ml	V2C	100		$720
BK2020032301-04		BK2020032301	50ml	Nb2C	100		$800
