CVD tungsten diselenide film: WSe2 multilayer continuous film





ID：BK2020073004

CAS：

price：
$429


Item ID：BK2020073004-19

specification：

5 minutes to choose the product plan

E-mail：mxenes@163.com

Detailed

Manufacturing method:

Chemical Vapor Deposition (CVD)

Product introduction:

Six Carbon Technology‘s WSe2 films are divided into many types:
1) A single layer of discretely distributed triangular-shaped single crystal grains, the triangle side length is generally tens to 100 microns.
2) A single-layer continuous film that continues to grow together from triangular grains.
3) Multi-layer WSe2 continuous film.
4) Substrate: WSe2 has many optional substrates, among which the sapphire substrate is a direct deposition product. Other substrates such as: SiO2/Si, 　silicon wafer, PET, PI, ITO, FTO, glass, metal substrates, etc. are transferred to the customer‘s required substrate by growing on sapphire.

Application areas:

Optoelectronic devices, microelectronic devices, biological sensing, chemical sensing and other fields.

Packaging and specifications

10*10mm, 15*15mm, 20*20mm, 2 inch disc, 4 inch disc or customized size specified by the customer.
Purified vacuum packaging, 1 piece/box, 5 pieces/box. 10 pieces/box.

Single layer WSe2 isolated die

Single layer WSe2 continuous film

Single and double layer hybrid WSe2

展开

Manufacturing method:
Chemical Vapor Deposition (CVD)
Product introduction:
Six Carbon Technology‘s WSe2 films are divided into many types:
1) A single layer of discretely distributed triangular-shaped single crystal grains, the triangle side length is generally tens to 100 microns.
2) A single-layer continuous film that continues to grow together from triangular grains.
3) Multi-layer WSe2 continuous film.
4) Substrate: WSe2 has many optional substrates, among which the sapphire substrate is a direct deposition product. Other substrates such as: SiO2/Si, 　silicon wafer, PET, PI, ITO, FTO, glass, metal substrates, etc. are transferred to the customer‘s required substrate by growing on sapphire.
Application areas:
Optoelectronic devices, microelectronic devices, biological sensing, chemical sensing and other fields.
Packaging and specifications
10*10mm, 15*15mm, 20*20mm, 2 inch disc, 4 inch disc or customized size specified by the customer.
Purified vacuum packaging, 1 piece/box, 5 pieces/box. 10 pieces/box.
Single layer WSe2 isolated die

Single layer WSe2 continuous film

Single and double layer hybrid WSe2,

Warm tip: the products supplied by Beijing Beike Xincai Technology Co., Ltd. are only used for scientific research, not for human body

Item ID	CAS	ID	Pack	Parameter	Stock	Make up	Price
BK2020073004-01		BK2020073004	多层连续薄膜	SiO2/Si（300nm氧化层）	100		$407
BK2020073004-02		BK2020073004	多层连续薄膜	SiO2/Si（其他厚度）	100		$450
BK2020073004-03		BK2020073004	多层连续薄膜	蓝宝石（单面抛光）	100		$234
BK2020073004-04		BK2020073004	多层连续薄膜	蓝宝石（双面抛光）	100		$234
BK2020073004-05		BK2020073004	多层连续薄膜	光学石英	100		$407
BK2020073004-06		BK2020073004	多层连续薄膜	柔性PET	100		$413
BK2020073004-07		BK2020073004	多层连续薄膜	硅片	100		$407
BK2020073004-08		BK2020073004	多层连续薄膜	高阻本征硅（>10000ohm.cm）太赫兹专用	100		$413
BK2020073004-09		BK2020073004	多层连续薄膜	SOI	100		$429
BK2020073004-10		BK2020073004	多层连续薄膜	PDMS	100		$554
BK2020073004-11		BK2020073004	多层连续薄膜	云母	100		$407
BK2020073004-12		BK2020073004	多层连续薄膜	SrTiO3钛酸锶	100		$413
BK2020073004-13		BK2020073004	多层连续薄膜	玻璃	100		$407
BK2020073004-14		BK2020073004	多层连续薄膜	ITO	100		$407
BK2020073004-15		BK2020073004	多层连续薄膜	金膜	100		$418
BK2020073004-16		BK2020073004	多层连续薄膜	银膜	100		$411
BK2020073004-17		BK2020073004	多层连续薄膜	铜膜	100		$407
BK2020073004-18		BK2020073004	多层连续薄膜	GaAs砷化镓	100		$429
BK2020073004-19		BK2020073004	多层连续薄膜	TEM铜网	100		$429
